YQ(Y)L Gas/Oil Fired Vertical Thermal Oil Boiler
Capacity: 1400-14000KW （1.2-12 Million Kcal）
Applicable Fuels: Natural Gas, Diesel oil, Light oil, etc.
Application Industries: Petroleum, Chemical, Pharmaceutical,etc.
This boiler adopts a three-pass circular coil structure with conical coils at the ends, effectively protecting the furnace wall at the boiler ends. Equipped with advanced combustion devices, this model features wide fuel adaptability, high energy efficiency, stable performance, and low-pressure high-temperature operation. Its complete automatic control system enables unattended operation.
For more information about this boiler model, please contact us !
Smart Flow Design Innovative variable flow technology ensures smoother thermal oil movement with reduced flow resistance. |
|  Maze-type Heat Exchange Structure The boiler's internal spiral coils adopt a three-layer maze layout, doubling the heat exchange area for more thorough heat absorption. |
Waste Heat Recovery Expert Equipped with heat recovery devices at the boiler tail that thoroughly "extract every bit of heat" from exhaust gases, lowering flue gas temperature by over 30℃. |
Quick-access Maintenance Design Features quick-opening doors and inspection ports, making internal examination and maintenance easily accessible. | |
Premium Insulation Kit Using refractory and insulation materials like a "down jacket" for boilers, keeping surface temperature ≤40℃ and safe to touch. |
Green Combustion Technology Incorporates Flue Gas Recirculation (FGR) technology to achieve both high combustion efficiency and NOx emissions meeting local environmental standards. |
| Model | Rated Heating Capacity (KW) | Rated Thermal Output (x104kcal/h) | Design Service Temperatur (≤℃) | Rated Working Pressure (MPa) | Thermal Efficiency (≥%) | System Installed Capacity (KW) | Maximum Transport size (m) (L×W×H) |
| YY（Q）L-7000Q | 7000 | 600 | 320 | 0.8 | 95 | 140 | 8.0×3.6×4.0 |
| YY（Q）L-8200Q | 8200 | 700 | 320 | 0.8 | 95 | 140 | 8.5×3.7×4.0 |
| YY（Q）L-9400Q | 9400 | 800 | 320 | 1 | 95 | 200 | 9.5×3.8×4.0 |
| YY（Q）L-10500Q | 10500 | 900 | 320 | 1 | 95 | 200 | 10.5×3.8×4.0 |
| YY（Q）L-12000Q | 12000 | 1000 | 320 | 1 | 95 | 240 | 12.4×3.8×4.0 |
| YY（Q）L-14000Q | 14000 | 1200 | 320 | 1 | 95 | 320 | 13.5.×4.0×4.2 |
| YY（Q）L-16500Q | 16500 | 1400 | 320 | 1 | 95 | 380 | Design on demand |
| YY（Q）L-18000Q | 18000 | 1600 | 320 | 1 | 95 | 450 | Design on demand |
| YY（Q）L-21000Q | 21000 | 1800 | 320 | 1 | 95 | 520 | Design on demand |
| YY（Q）L-23300Q | 23300 | 2000 | 320 | 1 | 95 | 600 | Design on demand |
| YY（Q）L-26000Q | 26000 | 2200 | 320 | 1 | 95 | 700 | Design on demand |
| YY（Q）L-29200Q | 29200 | 2500 | 320 | 1 | 95 | 825 | Design on demand |
1、What are your advantages in boiler production?
As one of the few listed companies in China holding a National Class A Boiler Manufacturing License, XianChuang Boiler has introduced internationally advanced production equipment and possesses a comprehensive industry certification system. We specialize in providing high-quality, "energy-saving, environmentally friendly, and innovation-driven" boiler products. From R&D design to manufacturing and installation, from intelligent operation and maintenance to energy-saving retrofits, we offer full lifecycle professional services, ensuring 100% project acceptance rate with seamless one-stop delivery.
2、What is your production capacity? Do you have your own production base?
We operate an 80-acre modern production base equipped with a 30,000-square-meter digital workshop, delivering an annual output of 40,000 steam tons of boilers to ensure efficient and stable production capacity.
3、Does your factory hold international/industry certifications?
We hold a National Class A Boiler Manufacturing License, along with ASME and CE certifications, and are recognized as a National High-Tech Enterprise. This robust dual-certification system (domestic and international) guarantees superior product quality.
 |  |  |
| MORE PROFESSIONAL | MORE EFFICIENT | MORE DEDICATED |
| Professional Service Team | Efficient & Prompt Response | Short Lead Time |
| Well-Established After-Sales System | Professional Industry Experience | High Quality | One-on-One Guidance |
 |  |  |
| MORE COST-EFFECTIVE | MORE RELIABLE | MORE COMPREHENSIVE |
| No Hidden Fees | Familiar with business processes | Extensive Coverage |
| High Value Services | Professional Industry Experience | Complete Turnkey Solutions |
