Thermal Oil Boiler
Capacity: 1400-29200KW （1.2-25 Million Kcal）
Applicable Fuels: Gas, Oil, Coal, Biomass, Electric
Application Industries: Petroleum, Chemical, Pharmaceutical,etc.
The company holds Class A boiler manufacturing license, American ASME and European CE certifications.
Reliable heat transfer oil boiler systems – biomass, gas, electric, and wood-fired solutions with 95% efficiency.
Get a Free QuoteA thermal oil boiler, also known as a heat transfer oil boiler or thermo oil boiler, is an industrial heating system that uses high-temperature thermal fluid to transfer heat indirectly. These boilers provide precise and continuous heating for industries like chemicals, food processing, textiles, and plywood hot press machines.
Biomass-fired thermal oil boilers & biomass pellet fire thermal fluid boilers
High efficiency thermal oil boilers with >95% heat transfer efficiency
Gas-fired and electric thermal oil heaters
Wood fired thermal oil boilers
YGL vertical thermal oil boilers & new horizontal gas fired thermal oil boilers
Heat conduction oil boilers & thermal oil heater boilers
Energy efficiency with counter-current design and low flue gas loss
Modular flexibility – integrated or split systems for easy transport
Precision control ±0.5°C for high-demand industries
Custom sizes available, includingvertical biomass wood logs firewood fired 600000 kcal thermal oil boiler for plywood hot press machines
5-year operating cost savings up to $100,000+
We supply solutions tailored to your needs, covering: thermal oil boiler price, biomass-fired thermal oil boiler, heat transfer oil boiler outlet, thermal oil boiler manifold, high frequency thermal oil boiler, wood fired thermal oil boiler, ygl vertical thermal oil boiler, new horizontal gas fired thermal oil boiler, and more.
Looking for the right thermal oil boiler for your project? Get in touch today.
Email: info@en-xc.com
WhatsApp / WeChat: +86 18006515657
| Model | YLW-1400S | YLW-1800S | YLW-2400S | YLW-2800S | YLW-3500S | YLW-4200S | YLW-4600S | |
| Rated thermal power | MW | 1.4 | 1.8 | 2.4 | 2.8 | 3.5 | 4.2 | 4.6 |
| x10⁴ kal/h | 120 | 160 | 160 | 240 | 240 | 360 | 400 | |
| Rated outlet temperature | (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
| Rated working pressure | (MPA) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Heat Efficiency | (≥%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| System installed capacity | (KW) | 55 | 63 | 76 | 86 | 105 | 125 | 155 |
| Min. transport dimension | Length(MM) | 5000 | 5600 | 6500 | 6500 | 7500 | 7400 | 8000 |
| Width(MM) | 2250 | 2250 | 2500 | 2550 | 2550 | 2870 | 2820 | |
| Height(MM) | 2450 | 2750 | 2800 | 3200 | 3200 | 3300 | 3350 | |
| Max. transportation weight | (KG) | 11000 | 12700 | 13500 | 14500 | 16500 | 25500 | 29000 |
| Model | YLW-6000S | YLW-7000S | YLW-8200S | YLW-9400S | YLW-10500S | YLW-12000S | YLW-14000S | |
| Rated thermal power | MW | 6 | 7 | 8.2 | 9.4 | 1.5 | 12 | 14 |
| x10⁴ kal/h | 500 | 600 | 700 | 800 | 900 | 1000 | 1200 | |
| Rated outlet temperature | (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
| Rated working pressure | (MPA) | 1 | 1 | 1 | 10 | 1 | 1 | 1 |
| Heat Efficiency | (≥%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| System installed capacity | (KW) | 170 | 193 | 150 | 160 | 160 | 260 | 320 |
| Min. transport dimension | Length(MM) | 8320 | 9000 | 9760 | 9760 | 10500 | 11200 | 10500 |
| Width(MM) | 3330 | 3330 | 3270 | 3500 | 3500 | 3560 | 4000 | |
| Height(MM) | 3250 | 3350 | 4010 | 4010 | 4010 | 4010 | 3500 | |
| Max. transportation weight | (KG) | 33500 | 36000 | 35000 | 24800 | 25000 | 27500 | 31000 |
Note: This table displays parameters for YLW Biomass Fired Thermal Oil Boiler. For other models of thermal oil boilers, please navigate to the corresponding webpage or contact customer service.
