Wall Thickness:30-110mm
Insulation layer thickness:0.06-0.12m
Product thermal conductivity:0.033w/m.k
Composite wall thermal resistance:1.978-6919（m³.k）/w
Temperature range:
-150°C to 90°C medium and low temperature pipeline insulation
Scope of application:
Thermal insulation fermentation tank, yurt, thermal insulation fish pond, sewage treatment tank.
Features:
Simple construction, fast splicing, good thermal insulation effect and long service life.
| Module model | Wall Thickness + Lumen + Wall Thickness | Insulation layer thickness | Product thermal conductivity λ | Composite wall thermal resistance R | Composite wall heat transfer coefficient K |
| unit | mm | m | w/m.k | （m³.k）/w | w/（m³.k） |
| 100 | 30+40+30 | 0.06 | 0.033 | 1.978 | 0.506 |
| 170 | 45+80+45 | 0.09 | 0.033 | 2.887 | 0.346 |
| 250 | 60+130+60 | 0.12 | 0.033 | 3.871 | 0.258 |
| 280 | 60+160+60 | 0.12 | 0.033 | 3.888 | 0.257 |
| 320 | 60+200+60 | 0.12 | 0.033 | 3.911 | 0.255 |
| 380 | 110+160+110 | 0.12 | 0.033 | 6919 | 0.445 |
Features:
Energy efficient
Healthy Indoor Environment
High wind resistance
Fire-resistance
High sound attenuating
Enhance steady temperature
Minimal Flood Damage
Fast track construction and reduce labour cost
Design Flexibility and variety of finishes
Less heavy plant and Equipment
ICF wall system
Passive house refers to the use of various energy-saving technologies to construct the best building envelope structure to maximize building air tightness and thermal insulation performance, so as to minimize ventilation heat loss and heat conduction loss;The main design concept of passive house is the combination of ultra-thick and high-efficiency thermal insulation materials,special doors and windows for passive buildings, and mechanical ventilation system with heat recovery to minimize energy consumption and ultimately maintain a comfortable environment in the room.
 |  |
 |  |
