Working Pressure: 0-5.0Mpa
Thermal Efficiency: ≥99.8%
Applicable Fuel: Electric
Applications: Food processing, packaging, etc.
An electrode boiler operates by immersing high-voltage electrodes in water of specific conductivity, utilizing water's conductive properties and high thermal resistance
characteristics to directly convert electrical energy into thermal energy. This process generates steam to achieve heating functions.
| Model | Rated Power | Boiler Dimensions | ||||||||
| 6.6kV | 10kV | 10bar(g) | 15bar(g) | 20bar(g) | 25bar(g) | 30bar(g) | 35bar(g) | Diameter | Height | |
| ETSH10Mi | 10 | 11.3 | 14.3 | 14.3 | 14.3 | 14.3 | 14.3 | 2400 | 5130 | |
| ETSH25Mi | 16 | 25 | 19.7 | 26.9 | 33.2 | 35.7 | 35.7 | 35.7 | 2900 | 5500 |
| ETSH35Mi | 23 | 35 | 24.2 | 34.7 | 45.3 | 50 | 50 | 50 | 3100 | 6130 |
| ETSH50Mi | 33 | 50 | 32.7 | 46.8 | 61.1 | 71.4 | 71.4 | 71.4 | 3600 | 6340 |
| ETSH70Mi | 40 | 60 | 42.1 | 60.3 | 78.6 | 85.7 | 85.7 | 85.7 | 4000 | 7260 |
